Mini dumper Qingdao Promising New 4.0T Mini Articulated Dumper Diesel nuevo

4.0T Articulated Wheel Dumper
HS Code: 8704109000

Application:
A dumper is a vehicle designed for carrying bulk material, often on building sites. Our compact dumpers are designed for any application from conventional building construction and landscaping to tunnel construction and demolition work. This three-way dumper provides an ideal solution as multi-function dumper when considerable manoeuvrability is required. They are ideal vehicles for transport and distribution of materials at building sites and for road works.

Feature:
1. Articulated joint
2. Excellent product quality
3. Durable and easy to service
4. Impressive turning radius for precision and efficiency
5. User-friendliness combined with excellent driver comfort
6. Power Swivel skips enable effective placement of load either side
7. Available with closed cab and heating

Technical Specifications:
1. Model: DP40
2. Payload: 4000kg
3. Operating Weight: 5250kg
4. Bucket Capacity: 2.5CBM
5. Max. Tractive Force: More than 55KN
6. Max. Breakout Force: More than 46KN
7. Max. Gradeability: 30Deg.
8. Overall Dimension (L x W x H): 4800x2050x3100mm
9. Min. Turning Radius: 4600mm
10. Engine Model: YUNNEI YN27
11. Engine Type: Four-cylinder, In-line, Water-cooled, 4-stroke Diesel Engine
12. No. of Cylinder-bore/Stroke of Engine: 4 – 84 x 90mm
13. Engine Power: 42kW (57HP)/2400rpm
14. Max. Torque of Engine: 270N.m
15. Min. Fuel Consumption Ratio: Less than 235g/kw.h
16. Torque Converter: YJ-265 Hydraulic Torque Converter
17. Gearbox Mode: Countershaft Power-shift
18. Gear Shift: 2 Forward, 2 Reverse
19. Max. Speed: 22km/h
20. Main Reducing Mode: Circular Arc Bevel Gear, Single Stage
21. Decelerating Mode: Single Stage Planetary Type
22. Wheel Base: 2100mm
23. Wheel Tread: 1500mm
24. Min. Ground Clearance: 290mm
25. System Working Pressure: 16Mpa
26. Fuel Tank Capacity: 80L
27. Service Brake: Foot Pedal Vacuum Booster, Air Over Hydraulic Caliper Disc Brake on 4 Wheels
28. Parking Brake: Hand Lever Flexible Shaft Controlled Externally Contracting Drum Brake
29. Tyre Type Specification: 20.5/70-16 Tire
30. Front Tyre Pressure: 0.22Mpa
31. Rear Tyre Pressure: 0.18Mpa

Optional Parts & Functions:
Hydraulic Joystick, 180 degree Rotating Dump Bucket, Bulldozing Blade, Self-Loading Bucket and Canopy.

Note:
1. All photos are for reference only. Machines shown may include optional parts.
2. Available optional parts include Hydraulic Joystick, 180 degree Rotating Dump Bucket, Bulldozing Blade, Self-Loading Bucket and Enclosed Cabin.
3. All specifications and design characteristics are subject to change without prior notice.
